Break Point LED Lights Features
1. Our Break Point LED strip lights adpot FW1834 IC, to make RGBW 4 in 1 addressable LED light tapes.
2. Work with SP108E, SP107E, SP638E LED pixel controllers, easy to control, can show color chasing, flow water, flashing, and kinds of running lighting effects.
3. Please use DC12V or DC24V power supply, such as LRS-100-12 or LRS-100-24. For DC12V lights, every 5cm can be cut. For DC24V lights, every 10cm can be cut.
4. Good flexibility, arbitrary bending to make different lighting design.
Product Parameters
Model: AMZ-1834-RGBW-60D-W10
Working Voltage: 12V, 24V DC
Typical Color: RGB Warm White 3000K, RGB Nature White 4000K, RGB Daylight White 6000K
Current Load: 5A in 12V, 2.5A in 24V
Rated Power: 10W/m, 3.05W/ft, 60W/roll
LED Qty: 60 LEDs/m, 300 LEDs per roll
Product Size: L5000*W10 (mm), L196.85*W0.39”
Cutting Unit: 50mm/1.97” in 12V, 100mm/3.94” in 24V
Certificate: CE, RoHS
Working Temperature: -20℃-+45℃
Beam Angle: 120°
Weight(G.w.): 250g
Dimmable: Yes
CRI(Ra): 85+
